Shuttle-used rockets roll into California to stand up Endeavour exhibit

September 11, 2020

— Two rocket boosters made from parts that launched on more than 80 space shuttle missions are now parked outside of Los Angeles, having moved a step closer to standing up the display of a retired NASA orbiter.

The twin solid rocket motors, which Northrop Grumman pledged to donate for the California Science Center's exhibit of the space shuttle Endeavour in 2017, were delivered over the past couple of weeks to the Mojave Air and Space Port, where they are being temporarily held in outdoor storage. The inert motor cases, which Northrop Grumman described as being "structurally representative" of the solid rocket boosters used during NASA's space shuttle program, were trucked in from the company's Promontory, Utah test facility after being prepared for their exhibit.

"We are excited to share a piece of our more than 30-year legacy with future generations to help inspire a new era of explorers," Charlie Precourt, Northrop Grumman's vice president for propulsion systems and a former space shuttle commander, said in a statement.

Since debuting Endeavour on horizontal display in 2012, the California Science Center has planned to exhibit the winged spacecraft vertically, as if it was back on the launch pad, stacked with a fuel tank and solid rocket boosters. Towards that goal, the science center originally obtained a pair of boosters assembled from a mix of flight-worthy, test and mock parts that had been on display at the Kennedy Space Center Visitor Complex in Florida.

But after obtaining NASA's final flight-worthy external tank, ET-94, in 2016, and conducting a review of the display plans, it was decided that a set of flight-worthy boosters were also needed to meet seismic and structural standards. Dennis Jenkins, a veteran shuttle engineer and director of the science center's project to display Endeavour, made the request to Northrop Grumman (at the time, Orbital ATK, which Northrop Grumman acquired in 2018), which led to the donation.

"As for the non-motor parts of the booster, we sourced a set of flight-representative aft skirts and frustums from NASA surplus and a set of forward skirts that were used for tests for NASA's Space Launch System (SLS) program that are currently in Utah," said Jenkins. "Northrop Grumman and NASA are providing most of the smaller parts, like booster separation motors, from surplus."

When the boosters' donation was first announced, the California Science Center was targeting 2019 for the opening of Endeavour's vertical display in the planned Samuel Oschin Air and Space Center. Although it now has all of the components for the space shuttle, the science center is still waiting to break ground on the new building.

"Honestly, we're still working on the fundraising. We've made good progress, but we are not quite there yet to start," Jeff Rudolph, president and CEO of the California Science Center, told collectSPACE. "We are optimistic that we will be able to start construction in the next year."

Once the project is funded and the Oschin Air and Space Center is ready for Endeavour, the two solid rocket motors that are now in Mojave will be brought to the science center with the same pomp and circumstance that the orbiter and external tank previously received.

"These are big, but they're a lot easier to move. It will still be a pretty cool thing to watch them come through the streets," said Rudolph.

The 149-foot (45 meter) solid rocket boosters produced most of the thrust needed for the space shuttle's first two minutes of flight. After expending their propellant, the twin boosters separated from the vehicle and descended under parachute to a splashdown for their recovery and reuse.

Northrop Grumman is using most of its leftover shuttle-era solid rocket motor hardware to support NASA's SLS, which is being built to launch astronauts to the moon. On Sept. 2, the day after the second of the two motors for Endeavour's exhibit arrived in Mojave, the company conducted a ground test with an SLS flight support booster in Utah, using parts previously flown on 43 shuttle launches.

Endeavour's well-used boosters include components that were part of 32 static ground tests and 81 space shuttle missions. The oldest cases, located at the top of each assembled solid rocket motor, helped launch STS-5, the fifth flight of the orbiter Columbia, in 1982. The most recent use was for STS-123, the 21st launch of Endeavour, in 2008.

In the interim 25 years, the cases were used on the maiden liftoffs of Challenger, Discovery, Atlantis and Endeavour (STS-6 in 1983, STS-41D in 1984, STS-51J in 1985 and STS-49 in 1992, respectively), as well as the mission that deployed the Hubble Space Telescope (STS-31 in 1990), the first and last Shuttle-Mir dockings (STS-71 in 1995 and STS-91 in 1998), the return of John Glenn to orbit (STS-95 in 1998), the ill-fated final mission of Columbia (STS-107 in 2003) and 22 missions to assemble the International Space Station.

Of Endeavour's 25 missions, 16 were flown using segments from its exhibit's two solid rocket motors.

The donation of the boosters builds upon a more than decade-long partnership between Northrop Grumman and the California Science Center. The company has sponsored the California State Science and Engineering Fair and several of its employees volunteer each year to advance STEM education by supporting various events. Northrop Grumman has also supported the center's annual Discovery Ball.

Endeavour will be the only vertical display and second full stack exhibit of a space shuttle, the latter after the Pathfinder fit-check orbiter mockup at the U.S. Space & Rocket Center in Alabama.




One of two solid rocket motors for the California Science Center's planned vertical display of space shuttle Endeavour is offloaded at Mojave Air and Space Port after being delivered from Northrop Grumman's test facility in Utah. The boosters will remain in Mojave until the science center's new Samuel Oschin Air and Space Center is ready. (California Science Center/Perry Roth Johnson)




A solid rocket motor comprised of parts that previously launched on numerous space shuttle missions is prepared for delivery from Northrop Grumman's Promontory, Utah test facility to Mojave Air and Space Port, to be stored until the California Science Center is ready to exhibit it with the orbiter Endeavour. (Northrop Grumman)




Artist's rendering of the vertical space shuttle Endeavour exhibit in the Samuel Oschin Air and Space Center at the California Science Center in Los Angeles. (California Science Center/Ron McPherson)




Case use history for the two Northrop Grumman solid rocket motors that will go on vertical display with the space shuttle Endeavour at the California Science Center in Los Angeles. (Northrop Grumman)



A "structurally representative" space shuttle solid rocket motor is seen before departing Northrop Grumman's test facility in Promontory, Utah for the Mojave Air and Space Port, where it will held in storage for the California Science Center's space shuttle Endeavour exhibit. (Northrop Grumman)



A large crane offloads a Northrop Grumman solid rocket motor for storage at the Mojave Air and Space Port until it is needed for the California Science Center's vertical display of the space shuttle Endeavour. (California Science Center/Perry Roth Johnson)



(California Science Center/Perry Roth Johnson)



(California Science Center/Perry Roth Johnson)



(California Science Center/Perry Roth Johnson)



(California Science Center/Perry Roth Johnson)



The retired space shuttle Endeavour debuted on horizontal display in the Samuel Oschin Pavilion at the California Science Center in Los Angeles on Oct. 30, 2012. (collectSPACE)



NASA's last flight-worthy space shuttle external tank, ET-94, arrived at the California Science Center in Los Angeles for display with the retired orbiter Endeavour on May 21, 2016. (collectSPACE)



Artist's rendering of the vertical space shuttle Endeavour exhibit in the Samuel Oschin Air and Space Center at the California Science Center in Los Angeles. (California Science Center/Ron McPherson)



(California Science Center/Ron McPherson)
