SpaceX lands historic recovered Falcon 9 rocket stage on display

August 22, 2016

— SpaceX's first recovered rocket stage has landed on display outside of the company's California headquarters 8 months after it made history.

The nine engine booster, which on Dec. 21, 2015, became the world's first rocket stage to help launch a payload into Earth orbit and then fly back and touch down near where it had lifted off, is now a 15-story-tall monument at SpaceX's offices and manufacturing facility in Hawthorne, California.

The Falcon 9 stage was erected on Saturday and Sunday (Aug. 20-21) at the intersection of Jack Northrop Ave. and Crenshaw Blvd., at the southeast corner of SpaceX HQ. It had previously been parked, lying horizontally a few blocks away, since being delivered from NASA's Kennedy Space Center in Florida in June.

The 165-foot-tall (50 m) first stage, part of the 20th Falcon 9 flown, is displayed in a similar configuration to the way it looked when it descended to SpaceX's Landing Zone (LZ-1) at Cape Canaveral Air Force Station. The stage, which launched with 11 Orbcomm communications satellites, has its grid fins extended and landing legs deployed.

The soot deposited on the stage's body during its historic landing has been mostly cleaned off, its logos have been repainted and most, if not all of its nine Merlin engines look to have been replaced by spent, stripped down versions. Otherwise, the vehicle appears to have been preserved as an artifact.


The Falcon has landed. Click to enlarge video in new pop-up window. (SpaceX)

"It's kind of unique. It's the first one we brought back," Elon Musk, SpaceX's CEO and chief technology officer, stated soon after the stage landed in December 2015.

Since that first recovery, SpaceX has successfully landed five more Falcon 9 first stages — one at LZ-1 and four on its autonomous spaceport drone ship, the latter an ocean-going platform used for when the Falcon 9's launch profile does not leave enough fuel for the first stage to fly back to the coast.

SpaceX has been working to perfect the landings so that the recovered stages can be reused, lowering the costs of putting payloads into orbit. Before shipping it to Hawthorne for its display, the Orbcomm stage (F9-021) was erected at Complex 40 in Cape Canaveral for a successful test fire on Jan. 15.

Another Falcon 9 first stage from a satellite launch in May has been delivered to SpaceX's test facilities in McGregor, Texas, for a series of on-going static firings. The company has said it may be ready to re-fly a recovered stage for the first time later this year.

SpaceX needed the Federal Aviation Administration (FAA) to approve its plan to erect the first recovered stage due to the display's height and its location adjacent to Hawthorne Municipal Airport. In March, the FAA concluded found "that the structure would have no substantial adverse effect" to the use of the surrounding airspace.

The agency did however, require red lights be added to the Falcon stage's display.

The stage, which can be seen from the surrounding area, is not the only artifact displayed at SpaceX's headquarters. Although closed to the public, inside the facility, suspended from the ceiling, is SpaceX's first Dragon capsule, which in 2010 became the first private spacecraft to be recovered from Earth orbit.




The first orbital rocket stage to land vertically after launch is now a monument at the SpaceX facility where it was built. (Bryce Allen)




A crane positions the 15-story-tall Falcon 9 stage before workers reattached its four deployable landing legs. (Bryce Allen)



Two cranes were used to take the Falcon 9 first stage from horizontal to vertical at SpaceX's Hawthorne, California headquarters. (Bryce Allen)

The following photos of the completed exhibit are from September 2017:



(collectSPACE)


(collectSPACE)

The following photo of the completed exhibit is from September 2018:



(collectSPACE)
